Chartpak Pickett Architectural Templates

Description

Chartpak Templates are made from durable matte finish, grey plastic. Indespensible when creating accurate to scale layouts. This template guide is suitable for use with technical pen or pencil. Precision-engraved apertures ensure single-stroke accuracy. Matte finish reduces glare. Ink risers facilitate clean, smudge-free inking and easy pick up/repositioning. Made with partially recycled, plastic materials.

## 1155i House Furnishings
The 5-1/2″ × 9-1/4″ template includes standard home furnishings for interior design.

## 111pi House Furniture Indicator
The 6″ × 10″ template contains standard furniture cutouts used for room planning and arrangements.

## 1153i House Plan
The 12″ × 8″ template includes architectural symbols used in designing kitchens and bathrooms. 1/4″ = 1 ft scale.

## 1150i House Plan and Plumbing
The 5″ × 7″ template includes house plan and plumbing fixtures.

## 1151i House Plan Fixture
The 8″ × 10″ template includes architectural symbols used in designing kitchens and bathrooms.

## 1170i Lavatory Planning
The 6″ × 9-3/4″ template includes all common American Standard brand of lavatory fixtures. 1/8″ and 1/4″ = 1 ft scale.

## 1162i Plumbing Elevation View
Contains standard lavatory and institutional plumbing fixtures. Four scales: 1/16
